L290NB Steel Forged Flange 1.0484 Flange EN 1092 1 Type 01
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | L290 | STEEL Number | 1.0484 |
|---|---|---|---|
| Type | Forged Flanges | Standard | EN1092-1 Type 01 |
| High Light | L290NB Steel Forged Flange,1.0484 Flange En 1092 1 Type 01 |
||
Product Description
L290NB forged flanges 1.0484 steel forged flange EN1092-1 Steel forged flanges
| Grade : | L290NB | ||
| Number: | 1.0484 | ||
| Classification: | Non-alloy quality steel | ||
| Density: | 7.85 g/cm ³ | ||
| Standard: |
|
| C | Si | Mn | Ni | P | S | Cr | Mo | V | N | Nb | Ti | Al | Cu | - |
| max 0.17 | max 0.4 | max 1.2 | max 0.3 | max 0.025 | max 0.02 | max 0.3 | max 0.1 | max 0.05 | max 0.012 | max 0.05 | max 0.04 | 0.015 - 0.06 | max 0.25 | CEV < 0.42 |
Mechanical properties of steel L290NB (1.0484)
| Rm - Tensile strength (MPa) | 415 |
| Rt0.5 - Yield strength for 0.5% total elongation(MPa) | 290-440 |
| KV - Impact energy (J) transverse, | 0° 40 |
| KV - Impact energy (J) longitud., | 0° 60 |
| A - Min. elongation at fracture (%) | 21-23 |
Equivalent grades of steel L290NB (1.0484)
| EU EN |
USA - |
Germany DIN,WNr |
||
| L290NB |
|
|
