Product Details
Material 1.0570 Material Grade S355j2g3
Flange Type Weld Neck Flanges Type Slip On Flanges
Leave a Message
Product Description

S335J2G3 Blind Pipe Flanges Flange 1.0570 Carbon Steel Weld Neck Flange Slip-On Plate Multi-Type Flange Customized





Product Name
Flange(304/F304 Pipe Fitting Wn RF/Rtj/FF ANSI/JIS/DIN/API 6A Cl150/Pn10/Pn16 Forged Stainless Steel Weld Neck Pipe Flange)
Pressure
150#-2500#,PN0.6-PN400,5K-40K,API 2000-15000
Standard
ANSI B16.5,EN1092-1, SABA1123, JIS B2220, DIN, GOST,UNI,AS2129, API 6A, etc.
Thickness
SCH5S, SCH10S, SCH10, SCH40S,STD, XS, XXS, SCH20,SCH30,SCH40, SCH60, SCH80, SCH160, XXS and etc.
Material
Stainless steel: A182F304/304L, A182 F316/316L, A182F321, A182F310S, A182F347H, A182F316Ti, 317/317L, 904L, 1.4301, 1.4307,
1.4401, 1.4571,1.4541, 254Mo and etc.
Carbon steel: A105, A350LF2, S235Jr, S275Jr, St37, St45.8, A42CP, A48CP, E24 , A515 Gr60, A515 Gr 70 etc.
Duplex stainless steel: UNS31803, SAF2205, UNS32205, UNS31500, UNS32750 , UNS32760, 1.4462,1.4410,1.4501 and etc.
Pipeline steel: A694 F42, A694F52, A694 F60, A694 F65, A694 F70, A694 F80 etc.
Nickel alloy: inconel600, inconel625, inconel690, incoloy800, incoloy 825, incoloy 800H,C22, C-276, Monel400, Alloy20 etc.
Cr-Mo alloy: A182F11, A182F5, A182F22, A182F91, A182F9, 16mo3,15Crmo, etc.
Shipping Ways
By sea, it is convenient for bulk orders.
Cheap shipping cost, usually takes 30-60 days.
By air, quick delivery, for not very heavyweight orders.
Cheaper than Express. Takes around 7-12 days.
By express, samples, and small order.
A little expensive, but very quickly, usually 7-10 days, door to door.



Grade : S335J2G3
Number: 1.0570
Classification: ??? According EN 10025-2 steel number 1.0570 named S355J2(+N) ???
Standard:
EN 10250-2: 2000 Open steel die forgings for general engineering purposes. Non-alloy quality and special steels





Chemical composition % of steel S335J2G3 (1.0570): EN 10250-2-2000
For forgings with an equivalent diameter or thickness > 100 mm the carbon content shall be agreed beetween purchaser and supplier.
C Si Mn Ni P S Cr Mo Al -
max 0.22 max 0.55 max 1.6 max 0.3 max 0.035 max 0.035 max 0.3 max 0.08 min 0.02 Cr+Mo+Ni < 0.48


Mechanical properties of steel S335J2G3 (1.0570)

Nominal thickness (mm): to 100 100 - 250 250 - 500
Rm - Tensile strength (MPa) (+N) 490 450 450

Nominal thickness(mm): to 100 100 - 250 250 - 500
Re - Upper yield strength (MPa) (+N) 315 275 265

Nominal thickness (mm): to 100 100 - 250 250 - 500
A - Min. elongation at fracture (%) longitud., (+N) 20 18 18
A - Min. elongation at fracture (%) transverse, (+N) 12



Equivalent grades of steel S335J2G3 (1.0570)

EU
EN		 Russia
GOST
S335J2G3
17GS
S345
