xGrade | S275JR | Material No | 1.0044 |
---|---|---|---|
Standard : | EN 10025-2: 2004 Hot Rolled Products Of Structural Steels | ||
High Light | stainless steel tubing,seamless stainless steel tubing |
S275JR Boiler exhaust Pipes , 1.0044 Boiler Flue Pipes Standard : EN 10025-2: 2004 Hot rolled products of structural
Grade : | S275JR | |
Number: | 1.0044 | |
Classification: | Non-alloy quality structural steel | |
Standard: |
|
S275JR Boiler exhaust Pipes , 1.0044 Boiler Flue Pipes
Nominal thickness =< 40(mm) C max = 0.21 Nominal thickness =< 40(mm) CEV max = 0.40 |
C | Mn | P | S | N | Cu | CEV |
max 0.22 | max 1.5 | max 0.04 | max 0.04 | max 0.012 | max 0.55 | max 0.42 |
S275JR Boiler exhaust Pipes , 1.0044 Boiler Flue Pipes
Nominal thickness (mm): | to 3 | 3 - 100 | 100 - 150 | 150 - 250 |
Rm - Tensile strength (MPa) Flat and long products | 430-580 | 410-560 | 400-540 | 380-540 |
Nominal thickness (mm): | to 16 | 16 - 40 | 40 - 63 | 63 - 80 | 80 - 100 | 100 - 150 | 150 - 200 | 200 - 250 |
ReH - Minimum yield strength (MPa) Flat and long products | 275 | 265 | 255 | 245 | 235 | 225 | 215 | 205 |
KV - Impact energy (J) longitud., | -20° 27 |
0° 27 |
+20° 27 |
Nominal thickness (mm): | to 1 | 1 - 1.5 | 1.5 - 2 | 2 - 2.5 | 2.5 - 3 |
A - Min. elongation Lo = 80 mm (%) parallel, | 15 | 16 | 17 | 18 | 19 |
Nominal thickness (mm): | 3 - 40 | 40 - 63 | 63 - 100 | 100 - 150 | 150 - 250 |
A - Min. elongation Lo = 5,65 √ So (%) parallel, | 23 | 22 | 21 | 19 | 18 |
S275JR Boiler exhaust Pipes , 1.0044 Boiler Flue Pipes
Weldability: This steel grade is generally suitable to welding |
S275JR Boiler exhaust Pipes , 1.0044 Boiler Flue Pipes
Equivalent grades of steel S275JR (1.0044)
EU EN |
USA - |
Germany DIN,WNr |
Japan JIS |
France AFNOR |
England BS |
Canada HG |
European old EN |
Italy UNI |
Belgium NBN |
Spain UNE |
China GB |
Sweden SS |
Poland PN |
Czechia CSN |
Finland SFS |
Austria ONORM |
Norway NS |
Russia GOST |
Inter ISO |
Portugal NP |
India IS |
|||||||||||||||||||||||||||||||
S275JR |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
