3312 Alloy Steel Seamless Pipes High Alloy Carburizing Grade For Heavy - Duty Applications
| Packaging Details | Standard exported package |
|---|---|
| Delivery Time | 5-8 working days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| High Light | alloy steel seamless tubes,seamless alloy steel tube |
||
|---|---|---|---|
Product Description
What is Alloy Steel , Alloy 3312 AISI/SAE 3312
Alloy AISI/SAE 3312 ----- a 3 ½% Nickel-Chromium Case Hardening Alloy Steel
What's the Alloy AISI/SAE 3312 specification,Alloy AISI/SAE 3312 chemistry, Alloy AISI/SAE 3312 equivalent, Alloy AISI/SAE 3312 Mechanical Properties? Alloy AISI/SAE 3312 manufacturer in China.
Alloy AISI/SAE 3312 Characteristics Any enquiry email us : service@okpipes.com
Alloy 3312 AISI/SAE 3312 High alloy carburizing grade for those heavy-duty applications requiring high core strength, toughness and fatigue resistance over and above the widely used AISI 8620.
Alloy 3312 AISI/SAE 3312 Core strengths in the order of 170,000 psi (1172 N/mm2) are attainable. It is the preferred grade for carburized parts in severe operating conditions with excellent low-temperature properties.
Alloy 3312 AISI/SAE 3312 3312 may also be used in the heat treated, non-carburized condition for many applications requiring extra strength and toughness. It is normally supplied in the annealed condition and hardness HB 212 would be typical.
Alloy 3312 AISI/SAE 3312 Typical Applications:
Heavy-duty gears, pinions, spline shafts, piston pins, transmission components, rock drilling bit bodies, plastic molds, etc
Alloy 3312 AISI/SAE 3312 Chemical Composition :
| C | Mn | P | S | Si | Ni | Cr |
| 0.11 | 0.47 | 0.10 | 0.002 | 0.27 | 3.33 | 1.47 |
Alloy 3312 AISI/SAE 3312 Typical Heat Treatment
Forging
− Commence 1215˚C max.
− Finish 925˚C Bury in Mica.
− Annealing
− 840˚C Furnace cool
− Normalizing
− 900˚C Air cool
− Hardened & Tempered (Uncarburized) - Heat to 815˚/ 840˚C and oil quench or Heat to 840˚/ 870˚C and air quench, then temper at 200˚/ 650˚C according to properties required.
− Case Hardening - single refining treatment. After carburizing at 900˚/ 925˚C, cool to RT. Reheat to 775˚/ 800˚C, oil quench and temper at 200˚C.
Alloy 3312 AISI/SAE 3312 Mechanical Properties
Typical as supplied, Annealed.
− Tensile Strength – 102,000 psi
− 2Tensile Strength – 704 N/mm
− Yield Strength – 80,000 psi
− 2Yield Strength – 552 N/mm
− Elongation – 24%
− Reduction of Area – 65%
− Hardness – HB 212
− Machinability – 40
