X20CRMOV11-1Boiler Steel 1.4922 Pressure Steel - BOILER STEEL
| Place of Origin | Japan |
|---|---|
| Brand Name | Globa |
| Certification | CE, PED, ISO |
| Model Number | 1''-48'' |
| Minimum Order Quantity | 1 Ton |
| Price | USD |
| Packaging Details | Standard exproetd package |
| Delivery Time | 5-8 working days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 10000 Ton |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Alloy Or Not | Is Alloy | Surface Treatment | Customerized,Varnished,black Painted,PE Coated |
|---|---|---|---|
| Application | Boiler Pipe | Technique | Hot Rolled,Cold Drawn,Cold Rolled,ERW,welded Steel Pipe |
| Standard | ASTM,DIN,JIS,GB,API | Special Pipe | Thick Wall Pipe,API Pipe,alloy Steel Pipe,boiler Pipe,0-+20P Tolerance |
Product Description
Bolier Steel X20CrMoV11-1, --1.4922 , 20H12M1F for work at elevated temerratures for pressure applications accoring to EN10216-2, EN10088-1, EN10302, PN-75/H-84024.
What's the alloy Steel X20CrMoV11-1 specification, alloy Steel X20CrMoV11-1 chemistry, alloy Steel X20CrMoV11-1 equivalent, alloy Steel X20CrMoV11-1 Mechanical Properties? alloy Steel X20CrMoV11-1 manufacturer
Alloy Steel X20CrMoV11-1 Steel Grade Chemmical Compostion
EN X20CrMoV11-1 Steel Grade Chemical Compostion %
| C: | Mn: | Si | P | S | Cr | Ni | Mo | V | Al | Cu |
| X20CrMov11-1 , X20CrMoV12-1 , 1.4922 | ||||||||||
| 0.17 -0.23 | <1.0 | 0.15 - 0.50 | <0.025 | <0.010 | 10.0 - 12.5 | 0.3 - 0.8 | 0.8 - 1.2 | 0.25 - 0.35 | <0.04 | <0.3 |
PN 20H12MF Steel Grade Chemical Compostion %
| C: | Mn: | Si | P | S | Cr | Ni | Mo | V | Al | Cu |
| PN 20H12MF | ||||||||||
| 0.17 -0.23 |
0.3 -0.8 |
0.150 0.50 |
<0.035 | <0.035 | 11.0-12.5 | 0.3 - 0.8 | 0.8 - 1.2 | 0.25 - 0.35 | ||
DIN X20CrMoV12-1, X20CrMoV12-1 Steel Grade Chemical Compostion %
| C: | Mn: | Si | P | S | Cr | Ni | Mo | V | Al | Cu |
| X20CrMoV12-1, X20CrMoV12-1 | ||||||||||
| 0.17 -0.23 |
0.3 -1.0 |
＜0.4 | <0.025 | <0.015 | 10.0-12.5 | 0.3 - 0.8 | 0.8 - 1.2 | 0.20 - 0.35 | ||
ISO X20CrMoNV11-1-1 Steel Grade Chemical Compostion %
| C: | Mn: | Si | P | S | Cr | Ni | Mo | V | Al | Cu |
| X20CrMoNV11-1-1 | ||||||||||
| 0.17 -0.23 | ＜1.0 |
0.150 0.500 |
<0.030 | <0.030 | 10.0-12.0 | 0.3 - 0.8 | 0.8 - 1.2 | 0.25 - 0.35 | ＜0.02 | ＜0.25 |
Alloy Steel X20CrMoV11-1 Introduction
Alloy Steel X20CrMoV11-1 is one of the main products of our company.
Application: work at elevated temerratures for pressure applications accoring to EN10216-2, EN10088-1, EN10302, PN-75/H-84024.
Alloy Steel X20CrMoV11-1 Mechanical Properties
| Tensile Strength | Elonggation | Impact Resistance | Yield Point |
| Rm690--840Mpa | A＞17% | KV 20℃＞20J | Rp0.2＞490Mpa |
Alloy Steel X20CrMoV11-1 equivalent the following grades
CSN422916 , 12CR10MOVNI70.47 , X20CRMONV11-1-1 ETC
